    Solar charge controller, Driven Type : Solar

    • Supply TypeManufacturer, Exporter, Supplier
    • Preferred Buyer Location All over the world

    Easy Photovoltech Pvt Ltd. is a reputed solar charge controller manufacturer in India. We deals in manufacturing and supplying high-quality solar charge controller at affordable prices. Our....
    View More Details
    Send Enquiry

    Company Information

    • calendar Member Since 15 Years
    • building Nature of Business Manufacturer

    Ask for more detail from the seller

    Contact Supplier
    Report incorrect details

    Product Details no_img_icon

    Easy Photovoltech Pvt Ltd. is a reputed solar charge controller manufacturer in India. We deals in manufacturing and supplying high-quality solar charge controller at affordable prices. Our products come equipped with various features such as low voltage disconnects (LVD) facility. Our charge controllers are ideal either for 12V, 6V and 24V systems, and for solar panels rated up to 60A. We also manufacture the device according to your needs and requirements.
    A solar charge controller or voltage regulator or solar panel regulator is designed to control the amount of energy from the soar PV panels going to batteries. It is an essential component of most of the solar charging systems. It is a must because it protects batteries from overcharging panel from reverse current flow.
    If you are looking for a reliable solar charge controller manufacturers, give a call to us. We are committed to providing a wide range of solar charge controllers at market’s best price. At Easy Photovoltech, we manufacture our products in our ultramodern manufacturing unit using high-grade materials.


    Features :
    • Clean & Silent source of Power
    • No fuel required
    • Provision of Battery Bank
    • Negligible Maintenance
    • No recurring fuel cost
    • Modular design
    • Simple installation
    • Savings on electricity bills
    • Transportation problems and uncertainty in availability of fuel are totally avoided by using solar photovoltaic systems.


    Technical Data :


    Charge Controller TypeSPL1210SPL1206
    Nominal Voltage12V/24V12V/24V
    Nominal SPV Power150W (12V) / 300W (24V)150W (12V) / 300W (24V)
    Self Consumption<6ma<6ma
    Battery Charging Current10A max10A max
    Charging MethodCC-CVCC-CV
    Charge ControlPWMPWM
    Over Load Current>10A>10A
    Max Load Current3 X reted Currnet3 X reted Currnet
    Display IndicationsLED (Low Battery, Charging, Over Load)LED (Low Battery, Charging, Over Load)
    ConnectionScrew Type Connector for 4 Sq mm wireScrew Type Connector for 4 Sq mm wire
    InstallationTable / wall MountingTable / wall Mounting
    Dimension (L X W X H) in mm170 X 100 X 55145 X 110 X 55
    BoxMS sheet box with non weatherproof power coatingMS sheet box with non weatherproof power coating
    Luminary Degree of ProtectionIP 20IP 20
    CoolingNatural air cooledNatural air cooled
    Ambient Temperature-20°C to +50° C-20°C to +50° C
    Temperature Compensation-.005V/Degree/Cell-.005V/Degree/Cell




    Technical Data :


    Charge Controller TypeSPL1220A
    Nominal Voltage12V/24V automatic selected
    Nominal SPV Power300W(12V)/ 600W(24V)
    Self Consumption<6ma
    Battery Charging Current20A max
    Charging MethodCC-CV
    Charge ControlPWM
    Over Load Current>20A
    Max Load Current3 X reted Currnet
    PV to Battery Drop* 200 mv at rated current
    Display IndicationsLED (Output On, Low Battery, Over Load, Charging)
    ConnectionScrew Type Connector for 10 Sq mm wire
    InstallationTable / wall Mounting
    Dimension (L X W X H) in mm185 X 130 X 85
    BoxMS sheet box with non weatherproof power coating
    Luminary Degree of ProtectionIP 20
    CoolingNatural air cooled
    Ambient Temperature-20°C to +50° C
    Temperature Compensation-.005V/Degree/Cell




    Technical Data :


    Charge Controller TypeSPL2440A
    Nominal Voltage24V/48V/96V
    Nominal SPV Power1200W(24V)/2400W(48V)/4800W(96)
    Self Consumption<6mA
    Battery Charging Current40A max
    Charging MethodCC-CV
    Charge ControlPWM
    Over Load Current>40A
    Max Load Current3 X reted Currnet
    PV to Battery Drop* 200 mv at rated current
    Display IndicationsLED (Output On, Low Battery, Over Load, Charging)
    ConnectionScrew Type Connector for 10 Sq mm wire
    InstallationTable / wall Mounting
    Dimension (L X W X H) in mm215 X 205 X 65
    BoxMS sheet box with non weatherproof power coating
    Luminary Degree of ProtectionIP 20
    CoolingNatural air cooled
    Ambient Temperature-20°C to +50° C
    Temperature Compensation-.005V/Degree/Cell
