Soldering machine

We are offering soldering machine
1. usage: automatic line carving, drilling and milling edge for circuit board;
2. maximum working size: 300mm×300mm;
3. working mode: 2.5 d double-sided processing mode;
4. control handle is made up of arm + fpga of embedded control system, there is double usb interface in control handle, realizing master-slave usb communication model, that is, as the main usb device, directly read u disk data, as the slave usb device, communicate with the computer, which can completely work off the computer;
5. all module driving mode, three step motor modules + driving chip united to drive xyz axis moving;
6. casting fuselage, y axis moves driving beam arm move, in sculpture and drilling process, no displacement of circuit board;
7. random configuration of processing data auxiliary processing software, data directly into the machine without any external software;
8. with function of x, y, z axis hardware and software limit;
9. high power spindle motor, higher processing precision, with memory function without electricity, no worries about outage;
10. handle human-computer interface: 128 * 64 dot matrix liquid crystal display + 18 multi-function keys, with simple and intuitive operation;
11. processing precision: ±0.05mm;
12. repeat precision: 0.01mm;
13. minimum processing line width: 4mil;minimum line gap 6 mil above;
14. suitable drilling flower: 0.3mm~3.175mm drilling handle: 3.175mm;
15. suitable milling cutter: 1mm~3mm cutter handle: 3.175mm;
16. processing speed: 0～3m/min(actual-time adjustable);
17. spindle motor: 800w frequency conversion motor the highest speed 40000 revolves/min;
18. step motor: 35w four phase step motor*3;
19. shaft driving mode: entire advanceding screw driving;
20. spindle movements itinerary: 60mm;
21. with mating pc control software, lifetime free upgrades;
22. working power: ac220v/50hz 1000w;
23. overall dimension: main engine: 580mm×610mm×550mm;
24. control cabinet: 400mm×250mm×590mm;
25. net weight: 105kg.
