Contact SupplierWe are offering fast moving, high performance printer carriage designs. General compatibility with a wide range of fluids makes the sl-128 aa jetting assembly extremely versatile.
Two electrically independent piezoelectric slices, each with 64 addressable channels, are combined to provide a total of 128 jets. The nozzles are arranged in a single line, at a 0.020 inch distance between nozzles. Resolutions up to 450 dpi are possible.
Features
80 picoliter calibrated drop size
resolutions up to 450 dpi
128 individually addressable, inline nozzles
lightweight and highly stackable
orientation independent
supports solvent and uv-curable based inks
dual ported for ease of flushing
optional temperature control
