Spt Laser 80w Co2 Laser Tube 1250*80mm

We are offering spt laser 80w co2 laser tube.
Spt c90
80w co2 laser tube
laser tube length: 1250mm
laser tube diameter: 80mm
laser tube power: 80w
laser tube peak power: 100w
lifetime: 10000hours
warranty: 6months
delivery time: 3 working days after payment.
Packing: plywood case with foam.
Dongguan spt laser glass sealed co2 laser tubes have the advantages of high quality, small size in volume and no need to refill gas. It is mainly used for cutting, sculpturing, marking and welding non-metal materials. It could be used in laser mould manufacturing too. In addition, our laser tubes are used widely in thin metal industry.
80w co2 laser tube manual
1. To make sure that the electrodes connections are right;
2. To install the cooling water pipe. Please install the tube under the principle that water should be irrigated from negative end to positive, input upsides and output downsides and the outlet can’t leak. Before using the tube, the water storage container should be full of water, then ensure that the water cooling tube after imputing water must have no bubble( must check each use).
3. The efficiency of co2 laser tube is about 15-30%.
4. When installing the laser tube, please make sure that its two stand points should be in the point that is in the 14 of the total length of the tube, leaving enough space for the high voltage of the tube and any metal surface. If the clearance is too narrow, then the high voltage used to trigger the tube will spark with the surface of metal, and thus lead to the destruction of the tube and even the damage of major electronic components of laser machine.
5. Users are suggested to add the automatic inspection device into the laser tube’s cooling water system in order to avoid the laser tube to be over heated and disordered because of water off. Please consult the supplier of the machine for details.
