Stainless Steel Wire Mesh for Filtering Applications

Get Latest Price

Sold By : P. R. Shah

Send Inquiry

Product Specifications

MaterialStainless Steel
TechniqueSS Wire Mesh
Weave StylePlain Weave, Twill,5 Heddle
ApplicationFilter
Number Of FlowerSs Wire Mesh
Length15m and 30m
Diameter0.028mm - 1.6mm.
Size0.043mm - 3.35mm.
Supply TypeManufacturer, Exporter

Preferred Buyer From : All over the world

Product Overview

We are manufacturer of Plain Weave stainless steel wiremesh.

We are manufacturing s.s. wiremesh from 304,304L,316 AND 316L grade materials.

We are manufacturing mesh from 8 mesh to 500 mesh as per customer requirements with various wire gauge.

We are manufacturing mesh from mtr up to 2 mtr width.

Specification

Mesh	SWG	Inch	MM	Inch	MM	Micron	Approx Percentage Open Area
4	12	0.1	2.64	0.15	3710	3710	34.14
4	13	0.09	2.34	0.16	4010	4010	39.98
4	14	0.08	2.03	0.17	4320	4.32	46,2846,2846,2846,2846,2846,2846,28
4	15	0.07	1.83	0.18	4520	4520	50.67
4	16	0.06	1.63	0.19	4720	4720	55.25
4	17	0.06	1.43	0.19	4920	4920	60.03
4	18	0.05	1.22	0.2	5130	5130	65.27
5	14	0.08	2.03	0.12	3050	3050	36.05
5	15	0.07	1.83	0.13	3250	3250	40.93
5	16	0.06	1.63	0.14	3450	3450	46.12
5	17	0.06	1.43	0.14	3650	3650	51.62
5	18	0.05	1.22	0.15	3860	3860	57.74
5	19	0.04	1.02	0.16	4060	4060	63.87
5	20	0.04	0.91	0.16	4170	4170	67.38
6	16	0.06	1.63	0.1	2603	2603	37.82
6	17	0.06	1.43	0.11	2803	2803	43.85
6	19	0.04	1.02	0.13	3213	3213	57.62
6	20	0.04	0.91	0.13	3323	3323	61.63
6	21	0.03	0.81	0.14	3423	3423	65.39
8	16	0.06	1.63	0.06	1545	1545	23.68
8	17	0.06	1.43	0.06	1745	1745	30.21
8	18	0.05	1.22	0.08	1955	1955	37.91
8	19	0.04	1.02	0.09	2155	2155	46.07
8	20	0.04	0.91	0.09	2265	2265	50.89
8	21	0.03	0.81	0.09	2365	2365	55.48
8	22	0.03	0.71	0.1	2465	2465	60.28
8	23	0.02	0.61	0.01	2565	2565	65.27
8	24	0.02	0.55	0.1	2625	2625	68.36
8	25	0.02	0.5	0.11	2675	2675	70.98
10	20	0.04	0.91	0.06	1630	1630	41.18
10	21	0.03	0.81	0.07	1730	1730	46.39
10	22	0.03	0.71	0.07	1830	1830	51.91
10	23	0.02	0.61	0.08	1930	1930	57.74
10	24	0.02	0.55	0.08	1990	1990	61.38
10	25	0.02	0.5	0.08	2040	2040	64.5
12	22	0.03	0.71	0.06	1407	1407	44.16
12	23	0.02	0.61	0.06	1507	1507	50.67
12	24	0.02	0.55	0.06	1567	1567	54.78
12	25	0.02	0.5	0.06	1617	1617	58.34
12	26	0.02	0.45	0.07	1667	1667	62
14	24	0.02	0.55	0.05	1264	1264	48.56
14	25	0.02	0.5	0.05	1314	1314	52.48
14	26	0.02	0.45	0.05	1364	1364	56.55
14	27	0.02	0.4	0.06	1414	1414	60.77
14	28	0.02	0.37	0.06	1444	1444	63.37
16	24	0.02	0.55	0.04	1038	1038	42.71
16	25	0.02	0.5	0.04	1088	1088	46.93
16	26	0.02	0.45	0.05	1138	1138	51.34
16	27	0.02	0.4	0.05	1188	1188	55.96
16	29	0.01	0.34	0.05	1248	1248	61.75
16	30	0.01	0.31	0.05	1278	1278	64.76
18	25	0.02	0.5	0.04	0.91	911	41.69
18	26	0.02	0.45	0.04	0.96	961	46.39
18	27	0.02	0.4	0.04	1.01	1011	51.34
18	28	0.02	0.37	0.04	1.04	1041	54.43
20	24	0.02	0.55	0.03	0.72	720	32.14
20	25	0.02	0.5	0.03	0.77	770	36.76
20	26	0.02	0.45	0.03	0.82	820	41.69
20	27	0.02	0.4	0.03	0.87	870	46.93
20	28	0.02	0.37	0.04	0.9	900	50.22
20	29	0.01	0.34	0.04	0.93	930	53.62
20	30	0.01	0.31	0.04	0.96	960	57.14
24	27	0.02	0.4	0.03	0.66	658	38.69
24	28	0.02	0.37	0.03	0.69	688	42.3
24	29	0.01	0.34	0.03	0.72	718	46.07
24	30	0.01	0.31	0.03	0.75	748	50
24	32	0.01	0.27	0.03	0.79	788	55.48
30	28	0.02	0.37	0.02	0.48	477	31.7
30	29	0.01	0.34	0.02	0.51	507	35.81
30	30	0.01	0.31	0.02	0.54	537	40.18
30	31	0.01	0.29	0.02	0.56	557	43.23
30	32	0.01	0.27	0.02	0.56	577	46.39
40	32	0.01	0.27	0.01	0.37	365	33.04
40	33	0.01	0.25	0.02	0.39	385	36.76
40	34	0.01	0.23	0.02	0.4	401	39.88
40	35	0.01	0.21	0.02	0.43	425	44.8
40	36	0.01	0.19	0.02	0.44	442	48.45
50	34	0.01	0.23	0.01	0.27	274	29.09
50	35	0.01	0.21	0.01	0.3	298	34.41
50	36	0.01	0.19	0.01	0.32	315	38.45
50	37	0.01	0.17	0.01	0.34	336	43.75
50	38	0.01	0.15	0.01	0.36	356	49.11
60	36	0.01	0.19	0.01	0.23	230	29.6
60	37	0.01	0.17	0.01	0.25	251	32.25
60	38	0.01	0.15	0.01	0.27	271	41.08
80	38	0.01	0.15	0.01	0.17	166	21.17
80	39	0.01	0.13	0.01	0.19	188	34.88
80	40	0.01	0.12	0.01	0.2	196	37.91
80	41	0	0.11	0.01	0.21	206	41.89
80	42	0	0.1	0.01	0.22	216	46.07
100	42	0	0.1	0.01	0.15	152	35.81
100	43	0	0.09	0.01	0.16	163	41.18
100	44	0	0.08	0.01	0.17	173	46.39
120	44	0	0.08	0.01	0.13	131	38.11
150	45	0	0.07	0	0.1	98	33.72
150	45.5	0	0.06	0	0.11	106	39.43
200	47	0	0.05	0	0.08	77	36.76
250	48	0	0.04	0	0.06	62	36.76
300	48	0	0.04	0	0.05	45	27.83
325	48.5	0	0.04	0	0.04	43	30.49
400	49.5	0	0.03	0	0.04	36	31.25
500	50	0	0.03	0	0.03	26	25.79
