    Steel.Iron Non Tipping Trailer, For Moving Goods

    • MaterialSteel.Iron
    • ApplicationMoving Goods
    • Total Carbohydrate1year
    • DrivenPneumatic
    • Supply TypeManufacturer, Exporter, Supplier, Retailer
    • Preferred Buyer Location All over the world
    View More Details
    Send Enquiry

    Company Information

    • calendar Member Since 9 Years
    • building Nature of Business Retailer
    • gst icon GST No. 06AAPFK0521P1Z2

    Ask for more detail from the seller

    Contact Supplier
    Report incorrect details
    • Product Details

    • Company Details

    no_img_icon

    • DrivenPneumatic
    • Number Of FlowerTipping Trailer
    • MaterialSteel.Iron
    • ApplicationMoving Goods
    • Total Carbohydrate1year
    • Outer Dimensions3048 x 1828 x 534 mm

    We are counted amongst the prominent Manufacturers, Suppliers, and Exporters of Non Tipping Trailer in Haryana, India. Non Tipping trailers are fabricated with the aid of progressive techniques and methods, to bring about a high-quality product. Heavy Duty structured framework brings in a greater strength and stability. The typical features like solid beam axle, good quality bearings & tyres, and CNC machined hub, enhances their durability & reliability.



    Description : Non Tipping trailers are fabricated to a very high quality standards. Heavy Duty structured framework brings in greater strength and stability. The typical features like solid beam axle, good quality bearings and tyres, CNC machined hub enhances durability & reliability



    Features

    • Flexibility of loading/unloading goods/materials saves overall operating cost of transportation.
    • World class hub, axle, bearing & tipping mechanism enchases life (Durability & reliability).
    • Front door fixed by nuts & bolts. Drop down side and rear doors for easy loading/unloading (All doors removable)
    • Easily transportable as it gets easily attached/mounted.
    • Well designed for towing and loading stability.


    Specifications

    Description

    KVM-5T

    KVM-9T

    KVM-12T

    Outer Dimensions

    10x6x1.75 feet

    (3048x1828x534mm)

    12x6x2 feet

    (3658x1828x610 mm)

    14x7x2 feet

    (4270x1828x610mm)

    Main Chassis (mm)

    150x75

    Floor Sheet (mm)

    4

    Side Wall Sheet (mm)

    2 (Corrugated)

    Tyres

    4 Nos. Of 7.5x16

    2 Nos of 7.5x16.2 Nos. Of 9.00x16

    Hitch Beam (mm)

    75x40

    100x50

    100x50

    Ring Hitch (mm)

    50 Dia.

    Axle (mm)

    75 Sqiare (Front & Rear)

    75 Square (Front), 90 Square (Rear)

    Axle Bearing (SKF)

    32214 inner and 32213

    -

    Weight (kg. Approx)

    1550

    1720

    2000

    Tractor Power (HP)

    50~70

    70~90

    90~110
