Steel plates, Brand Name : GSL

We are offering Steel Plates, Technical conditions for plates of SA516Gr65 HIC
1. Scope
The technical conditions apply to plates of SA516Gr65 HIC with thickness range 100mm-240mm use of GASCO project.
2. Adopt standard:
ASME SA516SA516M-10 Standard Specification for Pressure Vessel Plates, Carbon Steel, for Moderate- and Lower-Temperature Service
ASME SA20SA20M Standard Specification for General Requirements for Steel Plates for Pressure Vessels
ASME SA370 Standard Test Methods and Definitions for Mechanical Testing of Steel Products
3. Dimension, Shape, Weight and Permissible Deviation
The dimension, shape, weight and permissible deviation shall meet the requirements of ASME SA20SA20M.
5. HIC sampling method: Per heat number thickness heat treatment rules combine one group.
6. Package, marking and certificate
Package, marking and certificate shall conform to A20.
7. The third party inspection
The chemical composition, tensile test and Charpy -V impact test and HIC test for plates of SA516Gr65 HIC shall be witnessed by surveyor of IQI.
8. Delivery conditions
The delivery conditions for plates of SA516Gr65 HIC shall be Normalized.
9. Other requirements
The other requirements for plates of SA516Gr65 HIC shall be accordance with SA516SA516M-2010.
MTC accordance with EN10204: 2004 3.1
More technical details and the MTC require please contact us.
