Steel Rod Heating Machine

We are offering steel rod heating machine.
~major features:
- this equipment adopts the igbt inverter circuit in parallel connection, which has high load adaptability.
- it has such feaures as high power, fast heating speed, high efficiency and easy operation.
- as compared with other heating modes, it can significantly promote the economic benefits, improve the quality of heated work pieces and save the energy and material, alleviate labor intensity and improve the production environment.
- it has super small size, which can save the production space by 10 times.
- it is safe and reliable, and requires no equipments of ten thousand voltage, and thus can ensure the safe operation.
- the comprehensive full load design is available for 24-hour continuous operation.
Application of induction heating equipment:
a. Heating (hot forging, hot fitting and melting):
b. Heat treatment (surface quench):
c. Welding (braze welding, silver soldering and brazing)
d. Annealing (tempering and modulation)
parameter:
~model gys-100ab (three phase)
work power 220v-520v
maximum input current 150a
output power 100kw
fluctuating frequency 20-50khz
output current 400-4000a
the flow rate of cooling water: 0.08-0.16mpa 10lmin
water temperature protection point 50c
product size main : 790x695x1060mm
transformer : 865x420x650mm
net weight main : 100kgs
transformer : 70kgs
