Steel Shingle Roofing Sheet Roll Forming Machine

Steel Shingle Roofing Sheet Roll Forming Machine The steel shingle roofing sheet roll forming machne is fully automatic and controlled by computer .It is easy to operate , you just need to set the length and pieces in the touch screen , then it can work itself . Every roll forming machine can work about 8 hours , and it just needs one or two workers . In order to protect the machine for a long time , workers should be everyday clean the machine and add oil . 1. Metal Trapezoidal Roofing Tile Process Flow Decoiler- Feeding and Leveling device- Main Roll Forming System- PLC Control System- Hydraulic Cutting device- Discharge table. 2. Machine Parameter 2.1 Raw Material A. Suitable Material: Colored Steel Plate, Galvanized Board, Aluminum Plate; B. Width of the raw material: 1220mm;         C. Thickness: 0.3mm - 0.8mm; 2.2 Main Body A. Roller station: 16 rows;                           B. Diameter of shaft: ￠70mm, 45# steel; C. Roller material: 45# steel;                        D. Frame: 350 H steel; E. Operate: Manual and Automatic;             F. Working speed: 8-10 mmin; G. Size (L*W*H): about 7800*1550*1510 mm; 2.3 Power A. Motor power: 4 Kw,  Hydraulic power: 4 Kw; B. Voltage: 380V 50Hz 3Phases or Customization; C. Driving way: By Chain 3. Components of machine
