Stone Cage Nets

1. The stone cage nets profile:
Is the horn of metal wire weaving fractal nets (lujuewang), the use of columned made of metal line diameter is according to the size of the tiles are different. If the wire hexagonal metal coating, then use line diameter to 2.0 mm to 4.0 mm metal line, if is PVC coated wire weaving lujuewang, then use outside diameter for 3.0 mm to 4.0 mm of PVC (metal) line of line. Outer frame edge than hex cable is used no.1 line coarse.
Stone cage box-like by big norms lujuewang coupling and become, construction of rocks into its cage only can. Sealing
Specification: stone cage 2m x x x 1-m 1-m, 3m 1-m x 4m x 1-m, 2m x 1-m x 1-m, 1-m x 0.5 m, 4m x x 0.5 m, the 1-m can also according to customer request for the production. Surface protection condition has galvanized zinc alloy, and coated PVC etc.
2.The purpose: stone cage nets
control and guide rivers and floods
discharge dam and diversion dam
fine protective
prevent soil erosion
bridge protection
hold the soil structure
coastal defense works
port engineering
retaining wall
road protection
3. Stone cage nets specifications:
Mesh (MM) using the diameter (MM) using the wire (PVC wire) / ID / OD (MM) maximum width (M)
60X80 2.0-2.8 2.0/3.0-2.5/3.5 4.3
80X100 2.0-3.2 2.0/3.0-2.8/3.8 4.3
80X120 2.0-3.2 2.0/3.0-2.8/3.8 4.3
100X120 2.0-3.4 2.0/3.0-2.8/3.8 4.3
100X150 2.0-3.4 2.0/3.0-2.8/3.8 4.3
120X150 2.0-4.0 2.0/3.0-3.0/4.0 4.3
