Stone Engraving Machine, Brand Name : RODEO

we are offering name:rd-1015 stone engraving machine. stone engraving machine
first, the scope:
1.1 applies to marble, granite, bluestone, sandstone, artificial stone, tombstones, stone, tile, glass and other materials.
levels 1.2 granite and other hard stone carving to 3mm
1.3 marble, bluestone once carved to 3mm
1.4 do glass sculpture, glass thickness over 5mm
1.5 can be used for other woodworking, advertising material, the use of strong, wide range of applications.
second, the performance characteristics:
2.1 imported linear square rails, the double four slider, loading capacity, smooth operation, high precision, long life, under the knife precision.
2.2 machine uses steel seamless welding, rigid deformation it really work surface backing plate, high strength and good rigidity, machine loading capacity of up to 500 pounds.
2.3 constant power spindle motor, cutting intensity, high efficiency. good software compatibility, compatible typ3artcamcastmate wentai a variety of cad cam design software.
2.4 two-way tool cooling system, effectively improve the tool life.
third, the performance parameters:
3.1 model: rd-1015
3.2 working stroke (x × y × z): 900mm × 1500mm × 150mm
3.3 platform size: 1140mmx1720mm
3.4 repeat positioning accuracy: 0.05mm
3.5 maximum blank line speed: 8800mmmin
3.6 maximum operating speed: 8800mmmin
3.7 spindle power: 2.2kw
3.8 spindle speed: 0-24000rpm
3.9 run mode: stepper
3.10 operating voltage: ac220v50hz
3.11 run command: g code
3.12 operating system: pci card.
