Storage Pallet Racking Upright Roll Forming Machine

Material Of Cutting BladeCr12Mov, Quench HRC58-62
Forming Stations16 Stations
CuttingHydraulic Cutting Cr12Mov
Work Speed12-15m/min
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Storage Pallet Shelving and Racking Upright Roll Forming Machine for 80 90 100 120mm Upright Rack Profiles Main Specifications Suitable Material: thickness 2.0-2.5mm, Galvanized coil or carbon....

View More Details

Send Enquiry

Company Information

Wuxi Techwell Machinery Company limited

Wuxi

View Number

Member Since 8 Years
Nature of Business Supplier
Year of Establishment 2005

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

Storage Pallet Shelving and Racking Upright Roll Forming Machine for 80 90 100 120mm Upright Rack Profiles
Main Specifications
Suitable Material: thickness 2.0-2.5mm, Galvanized coil or carbon steel
Working Speed: 12-15mmin
Forming Stations: 16 stations
Roller Material: Cr12Mov, Quench HRC58-62
Shaft Material: 45# Advanced Steel
Shaft Diameter: 75mm
Total power: 22.5kw
Decoiler: Manual decoiler or Auto Decoiler or Hydraulic Decoiler (Depend on customer's requirement)
Drive Type: Chain Drive
Punching Type: Hydraulic punching
Cutting Blade: Cr12Mov, quench HRC58-62
Cutting Type: Hydraulic cutting
The whole machine is controlled by industry computer-PLC
PLC: PANASONIC Brand
Encoder: Omron
Inverter: YASKAWA Brand
Weight of Machine: About 13T
Working Flowing
Decoiler – Feeding - Leveling– Servo Feeding –Hydraulic Punching – Pinch Feeding --- Main Roll Forming – Straightness Device – Hydraulic Cutting -- Run out table
