Capacity : Up to132 m3hr
Head : Up to 40 Mtr.
Temperature : 45°C
HP : 0.75 to 10 (1 to 3 HP in single phase)
RPM Up to 2880
Delivery Size : 32 mm to 100 mm
Solid Size : 50 mm
Connection : DOL
Voltage & Phase : 415 V , 3 Phase 215 V, 1 Phase Up to 3 HP
InsulationProtection : ‘F’ Class IP 68
Motor : Two pole continues duty dry type squirrel cage nduction Motor
Cable : PVC Insulated Double heated Copper Conductor Flexible Cable
Mechanical Seal : Bi-Directional Twin Mechanical Seal with Various face
combination looking to the application.
M.O.C. : C.I, C.S.
Optional Parts : Impller, Casing, Wear Plate with Various
M.O.C. Bronze, CF8, CF8M, CD4MCU
Applications:
Muddy water transfer.
Swimming pool.
Dewatering of ponds, basement of huge building.
Power plant..
Effluent transfer, ETP,STP, waste water treatment plant.
Used in hotel, hospitals, railways, dairy, chemical ind, sugar, steel, cement,
food beverages etc…
