Supermarket 2 Inch Direct Thermal Printer

Supermarket 2 Inch Direct Thermal Printer
Features:
Reliable printer mechanism
High speed
Wide input voltage range DC12~24 V
Full partial cutting mode (by adjustable)
Panel mounting method
Multiple optional accessories
Specification:
mechanism： MS628MCL101
Printing method Thermal dot line
Dotsline 384 dotsline
Dot pitch 8 dotmm
Paper width 58 mm
Printing width 48 mm
Paper thickness 54~100 um
Printing speed 100 mms
Paper feed direction 180° horizontal
Paper loading Auto loading
Font size ASCII:9*17;12*24;
Chinese: 24*24
Dimension (L*W*H) 98*81*60 mm
Weight Approx 0.23 kg
Reliability Cutter: over 7,000,000 cuts
Thermal head: over 100 km
Ambient environment Work temperature -10 ℃~50℃
Work humidity 20~85% RH
Storage temperature -25℃~70℃
Storage temperature 10~90% RH
Interface RS-232 TTL
power supply DC 12~24V3A
Command set ESCPOS
System WinXPWin7Win8AndroidLinux OS
Accessories: paper near end sensor;
Roll spindle
Paper holding unit;
Paper bezel
Interface connector
Power supply unit
Cable
Applications:
Kiosk, parking machine, queue management system, gas pumps station, ticket dispenser, lottery device, coupon machine, self-service terminal, ID automation, attendance terminal and more.
