    We are offering surveying automatic levels.
    the surveying automatic levels offered by us are specially designed for offering enhanced productivity for a longer time period. Featuring a tough body in a compact and sealed design, these offer resistance to dust, water and humidity. Manufactured using high grade components, these surveying automatic levels can easily endure vibration, while providing easy installation and sighting.
    why our surveying automatic levels?
    accurate and dependable automatic compensator with four suspension wires that have excellent tensile strength and specialized magnetic damping system. It offers resistance to temperature fluctuations and shocks.features dual knobs in endless horizontal motion drives for better aiming and operationreadout window located directly below the eyepiecespecially designed telescope with sharp view and 20cm ultra-short focus distance, suited for confined locations and strain-free viewingeasier horizontal angle measurement :1° or 1 gon unitsfreely rotatable circlequicker right angle setting for proper layout and alignmentstadia lines on reticle measured by easily multiplying the length of staff between top and bottom by 100easier adjustment facility for reticle and circular levels using one and two screws respectively.
    standard equipment :
    instrumentvinyl rain covertool kitlens capplumb boboperator's manualcleaning clothhard carrying casemanufacturer’s 5-year limited warranty


    Specifications :

    ModelB40
    Telescope
    Length215mm (8.46in.)
    Magnification24x
    Objective aperture32mm (1.26in.)
    Resolving power4"
    Field of View (at 100m/328ft.)1°25' (2.5m / 8.2ft.)
    Minimum focus0.2m (7.9in.) from end of telescope
    0.3m (1ft.) from instrument center
    ImageErect
    Reticle patternCross line
    Stadia constant0
    Stadia ratio100
    Focusing knob1-speed
    Sighting aidGun sight
    Lens hood-
    Accuracy (standard deviation for 1km double run leveling)
    Without micrometer2.0mm (0.08in.)
    With micrometer
    Compensator
    TypePendulum compensator with magnetic damping system
    Setting accuracy0.5"
    Working range±15'
    Circular level
    Sensitivity10' / 2mm
    MirrorPlane mirror
    Horizontal circle
    Diameter103mm (4.1 in.)
    Graduations1° / 1gon
    General
    Horizontal motion driveClampless, endless, double-sided knobs
    Water resistanceIPX6 (EC 60529:2001)
    Operating temperature-20 to +50°C (-4 to +122°F)
    Width130mm (5.12in.)
    Length215mm (8.46in.)
    Height135mm (5.31in.)
    Weight1.7kg (3.7 lb.)
