Contact SupplierWe are offering swing gate turnstile (cpw-322ag) developed by cmolo has the widest passage which available for handicaped only, or users with luggage or package and bicycles.
Size: 868*168*1100mm
framework specifications:
framework: 304 (standard) 316 grade stainless steel
thickness of ply: 1.5mm (standard) 2.0mm
finishing: brushed surface (standard) polishing surface
material of obstacle: stainless steel (default) organic glass (optional) tempered glass (optional)
lane width: 700 mm (default)
design sketch of swing gate cpw-321asp
customized features:
alternative materials, finishes and custom design
access control system integration
ticket system integration
camera system integration
thermostat system integration
remote-controlled button
usage counters
waterproof and dustproof design: ip55 for mechanical module, ip65 for electric module
applications:
office building
government
colleage and university
elegant hotel
super market
technical parameters
power and voltage ac 220v ac 85 ~ 230v operation voltage dc 24v
machinery
mechanism mtht�
lossless mechanism driving motor dc brushless motor
communication
interface rs485 rs232 rated power 90w
passing speed 30 ~ 45 people min working
environment indoors
operation
temperature - 15 ~ 60centigrade humidity
temperature 0 ~ 95%
(non-condensation)
control inputoutput 6 channels relay control output 4-channel dry contact signal input
