Contact SupplierHigh Tensile PVC covered steel wire hose are thin walled and light in weight and are very flexible for industrial purposes. Sizes produced are10 mm ID to 200 mm ID.
Our hoses have a reinforcement of PVC insulated high carbon grade II spring steel wires from 200 Uts Kg/mm2to 220 Uts Kg/mm2 (United Tensile Strength). Also available in high grade III for heavy duty pipes.
Super Flexibility
Our Hoses are highly flexible and will flex on it own diameter without deformation or any reduction in its cross section. This special feature reduces installation time in the most unapproachable area of application.
Temperature Resistance
Our Hoses can withstand a temperature from 150°C to 600°C and are inherently flame retardant. However hoses can be supplied on special request with heat resistant PVC which can withstand temperatures from -300°C to 1050°C.
Electrical Resistance
Our Hoses have excellent dielectric properties. There is no danger of short circuit taking place due to steel wire, as it is fully insulated with pvc. There are no other harmful effects due to spring steel wire, when used near panels. Infact, it is a kind of an armoring and protects the cable inside.
Self Extinguishing
Our Hoses do not propagate fire. It is self-extinguishing. The hose will cease to burn as soon as direct source of flame is removed.
Chemical Resistance
Our Hoses resist most chemicals, acids, alkalis, greases, petrol, etc. They are waterproof and suitable for application in damp environments.
Mechanical Resistance
Our Hoses are have very high crush resistance for development of "kinks" and excellent shockproof properties due to the spring steel wire reinforcement.
Code No. | Inner Dia of Hose (mm) | Standard Pkgs. (No's) |
---|---|---|
RPG 9.00 | 10 | 100 |
RPG 13.50 | 15 | 100 |
RPG 16.00 | 20 | 100 |
RPG 21.00 | 25 | 100 |
RPG 29.00 | 30 | 50 |
RPG 40.00 | 40 | 50 |
RPG 48.00 | 50 | 50 |
