Radical Square General Purpose Centrifuge

Specifications:

General Purpose Bench Top Laboratory Centrifuge Machine.

Heavy duty C.R.C. construction finished with powder coating.

Double walled ABS injection moulded lid which is light weight to avoid accident.

Inter lid lock and metallic centrifuge bowl for safety.

Microprocessor based programmable speed control from 500 to 5200 r.p.m depending upon the type of rotor and Digital timer (0-59 minutes)

4 lines, 20 characters. LCD Display for set time, run time, set and run rpm, rcf.

Last test parameter recall and display automatically on LCD.

50 programmes can be stored in memory and automatic rotor identification on display.

Additional electronic lid lock which does not allow to open lid when machine is running and opens automatically after centrifuge time is over. Calibration window on lid.

Dynamic brake (automatic) and imbalance detector are provided.

Selection of 3 acceleration + 4 deceleration profile with fast spin option.

Rotor Heads available for this machine are following:

Swing Out 16x15ml. Max Speed on the head 4400 rpm

Swing Out 12x15ml. Max Speed on the head 4400 rpm

Swing Out 8x15ml. Max Speed on the head 5200 rpm

Swing Out 6x50ml. Max Speed on the head 4000 rpm

Swing Out 4x50ml. Max Speed on the head 4400 rpm

Angle Heads 16x15ml. Max Speed on the head 5250 rpm

Angle Heads 12x15ml. Max Speed on the head 5250 rpm

Angle Heads 8x15ml. Max Speed on the head 5250 rpm

Angle Heads 6x50ml. Max Speed on the head 5250 rpm

Angle Heads 4x50ml. Max Speed on the head 5250 rpm

Angle Heads 4x100ml. Max Speed on the head 4000 rpm

Angle Heads 24x15ml. Max Speed on the head 4000 rpm

Angle Head 24 Vacuutainers. Max Speed on the head 4000 rpm

Angle Heads 32 tube of 12x75 mm Max Speed on the head 4000 rpm

Angle Heads 12x100 mm of Borosil for serum separation Max Speed on the head 4000 rpm
