Contact SupplierCounting of manufactured products has become of primary importance in the pharmaceuticals due to the need to account for the production volumes. In this regard, Harsiddh is pleased to offer modern state of the art tablet capsule counting and filling machines. Our product portfolio includes automatic capsule counting and filling machines, electronic tablet counting and filling machine, multichannel tablet counting machine, tablet counting and filling lines as well as tablet capsule counting and packing line.
Our specially designed automatic counting machines pack and count any type and size of tablet, capsules, caplets, soft gels pills and other solids. After extensive research by experts, our company developed a new patented filling part that ensures no breakage of products when packaging.
The counting is 100% accurate due to advanced sensors to detect the products even when moving at high speeds. The machine is fitted with easy to use and ergonomic HMI interface and a state of the art PLC to make control and operation easy. In addition, the control system implement “no product” “no count” as well as removing broken bottles and tablets.
To minimize idle times and maximize productivity, these machines do not require change of parts when filling different products. The filling machines are compact with ether a single or double conveyor systems. The delrin type conveyor is suitably designed for smooth, vibration and noise free operation.
Salient Features
Model | HEC – TCF – 8 | HEC – TCF – 12 | HEC – TCF – 16 | HEC – TCF – 24 |
Output | 30 to 40 Bottles / Minute (Depends on count) | 40 to 60 Bottles / Minute (Depends on count) | 60 to 80 Bottles / Minute (Depends on count) | 80 to 100 Bottles / Minute (Depends on count) |
Counting Channels / Tracks | 8 Counting channels / tracks | 12 Counting channels / tracks | 16 Counting channels / tracks | 24 Counting channels / tracks |
Tablet / Capsule sizes | Tablets Dia. 5 to 12mm, Irregular shape, Pills Dia. 3 to 12mm Capsules “0” to “5” |
Tablets Dia. 5 to 12mm, Irregular shape, Pills Dia. 3 to 12mm Capsules “0” to “5” |
Tablets Dia. 5 to 12mm, Irregular shape, Pills Dia. 3 to 12mm Capsules “0” to “5” |
Tablets Dia. 5 to 12mm, Irregular shape, Pills Dia. 3 to 12mm Capsules “0” to “5” |
Container type | Round or flat (Glass or pet) |
Round or flat (Glass or pet) |
Round or flat (Glass or pet) |
Round or flat (Glass or pet) |
Container Size | Neck diameter 25mm to 40mm & Body Diameter 40 to 60mm, Height 40 to 240mm | Neck diameter 25mm to 40mm & Body Diameter 40 to 60mm, Height 40 to 240mm | Neck diameter 25mm to 40mm & Body Diameter 40 to 60mm, Height 40 to 240mm | Neck diameter 25mm to 40mm & Body Diameter 40 to 60mm, Height 40 to 240mm |
Working range | Adjustable from 2 to 9999 pieces | Adjustable from 2 to 9999 pieces | Adjustable from 2 to 9999 pieces | Adjustable from 2 to 9999 pieces |
Power Requirements | 0.5 H.P., 230 Volts, 50 Hz, 1phase | 1 H.P., 230 Volts, 50 Hz, 1phase | 1.5 H.P., 230 Volts, 50 Hz, 1phase | 2 H.P., 230 Volts, 50 Hz, 1phase |
Dimensions | 1200mm X 950mm X 1280mm | 1400mm X 1350mm X 1500mm | ||
1600mm X 1350mm X 1500mm | 1800mm X 1450mm X 1700mm | |||
Direction | Left to right Or Customised | Left to right Or Customised | Left to right Or Customised | Left to right Or Customised |
Weight | 140 Kgs. | 210 Kgs. | 350 Kgs. | 400 Kgs. |
Remark | Production capacity is subject to type and size of the tablets, capsules, pills, bottles as well as the quantity filled in each bottle |
