Contact SupplierTechnical Parameter
Model: TF-FZG-20
Shelf Freeze-Dried Area: 2 square meters
Shelf Temp: -30~+80 degrees centigrade
Shelf Temp.Difference: 1 degree centigrade
Cool Trap Coil Temperature:
Dewatering: 25kg
Ultimate Vacuum: 10Pa
Cooling Water(
Defrosting Method: Spray+Water flooded
Use Environment: temperature 5~-30 degrees centigrade
relative humidity
Total Power: 22kw
Equipment Installation Area And Height: 15(square meters)x2.5(meters)
Feature:
1.The process of pre-freezing and drying finishes in situ, so it automates the dry process and easy to operate.
2.Cyclic medium is in the shelf. The temperature is adjustable and temperature error is within 1 degrees centigrade, so it will make freezing and heating effect more uniform.
3.The machine can be operated by TP-LCD and controlled by PLC, so it can monitor the running conditions of equipment in real time.
4. The equipment can be connected with computer and store freeze-drying curves by remote control.
5.The equipment is integral-designed, so it is easy to transport and install, besides it can save space.
6.The machine can be connected with CIP (clean in space) , SIP(sanitization in place) and hydraulic plug system.
