Shunxing Textile Waste Recycling Machine

We are offering gm-400-6 textile waste recycling machine.
useage:
our textile waste recycling machine recycled kinds of textile waste (knitting hosiery fabric rags , hard waste thread , polyester ,cloth waste leftover of garment ) get the fiber from these waste enable use for rotor spinning and any other purpose ,make a good use of waste material will save cost , the fiber will be instead of raw cotton .make bebefit .
technical data of textile waste recycling machine
aa. 400-6 recycling machine
main technical parameter:
01. Nos. Of roller / chamber : six cylinders /chambers
02. Nos of roll dia : 400mm
03. Front roll dia : 400mm
04. Back roll dia : 400mm
05. Dust basket dia : 530mm
06. Taker in wire
1) first cylinder 4.5 /tpi
2) second cylinder 6 /tpi
3) third cylinder 7/tpi
4) forth 7.5tpi
07. Outside dimension : 7200*1720*1160 mm (l*w*h)
08. Nos. Of motor & capacity :
motor: first 11kw one set ; others 7.5kw three sets
capicaty : 150-200kgs /hour
09. Distance of roll and feed plate: 300mm
10. Distance of feed roll and feed plate: 50mm
bb. Opening machine mqk-1060 opening machine
01. Output :150-200kgs /hour
02. Roll diameter : 600mm steel cylinder
03. Rotation speed : 1350rpm
04. Dust basket : 630mm
06. Fan machine : 1.5kw one set
07. Chain : four pieces
08. Power : 18.5kw
09. Taker in wire : 3.5-4.5tpi
10. Dimension : 2600*1450*1550 mm about
cc. Cutting machine qd-350 cutting machine
technical parameter
01. Out put : 1000-1500kgs/hour
02. The blade roller dia : 320mm
03. Speed of the roller : 230rpm
04. Nos. Of motor blade roller : y132s-8,5.5kw 1 set
feeding and discharging y 90l-4,1.5kw 1set
05. Chief bearing : 6216e 4 (blade roller)
06. Conveyor belt :
(1) 380×2100×4 1(feeding part)
380×2750×4 1(discharging)
