Three Way Globe Valve

As the name suggests, Three Way Globe Valve has three openings and two seats. The Three Way Globe Valve is used to change the medium flowing direction and distribute the medium evenly. Three Way Globe Valve ensure a longer functional life, owing to excellent weatherability, resistance against corrosion and high compressive strength.

Technical Specifications :

• Design standard : ASME B16.34, GB/T 12235, BS1873
• Face to face standard : ASME B16.10 GB/T 12221
• Flange ends : ASME B16.5, GB/T 9113
• Pressure test : API 598, GB/T 13927


Product Specifications :

• Body material : carbon steel, stainless steel, alloy steel
• Nominal diameter : 1/2", 24", DN15~DN600
• Pressure range : Class150, 2500, PN10~PN420
• Working temperature : -196^oC, 560^oC
• Operation :  wrench, worm gear, electric,etc.

Design Features : Sealing surface adopts sphere sealing, making the sealing face line-contact with each other, guaranteeing reliable tightness, and preventing scarring. High abrasion-resisting and erosion-proof performances. The valve is designed as a back seal structure, ensuring no medium leakage occurs in the stuffing box, reliable tightness and online replacement of packing. Its valve stem sealing is realized by the collaboration of flexible and woven graphite, ensuring a more reliable tightness.

Application : Chemical fertilizer, mining, metallurgy, aluminum oxide and other industries
