For Ina Cylindrical Roller Bearings, the Misalignment Factor also is a Measure of the Effect of Bearing Axial Load On Life. Axial Loading of the Bearing Causes a Moment to Be Generated About the Roller Center, Thus Shifting the Roller Raceway Contact Stresses Toward the End of the Roller, Similar to Bearing Misalignment.
the Additional Informations of Ina Cylindrical Roller Bearings Sl024920 are Shown as Below:
d 100 Mm
d 140 Mm
b 40 Mm
c 20 Mm
d1 116,4 Mm
e 129,6 Mm
rmin 1,1 Mm
s 2 Mm Axial Displacement
nncl4920v Designation to Din 5412
m 1,9 Kg Mass
cr 191000 N Basic Dynamic Load Rating, Radial
c0r 370000 N Basic Static Load Rating, Radial
cur 47500 N Fatigue Limit Load, Radial
ng 2700 1/min Limiting Speed
nb 1720 1/min Reference Speed
