Tube Filling, Sealing and Crimping Machine

The company has emerged as a highly acclaimed Manufacturer, Exporter & Supplier of Tube Filling, Sealing and Crimping Machine. The Tube Filling, Sealing and Crimping Machines are known for their versatility and high efficiency. The company offers the Best Tube Filling, Sealing and Crimping Machine at the best prices on a timely basis.
Features

• (Rotomax x 50) Optimum speed 50 tubes / Minute.
• (Rotomax x 35) optimum speed 35 tubes / minue.
• Filling accuracy 1% of fill weight.
• Proven high quality hot air sealing system for plastic & laminated tubes.
• Filling system-positive suction & Displacement.
• Easy & fast changeovers.
• Turret indexing device general mechanism /cam indexing mainfold
• A combination sealer for both metal tube folding, laminated & plastic tube sealing.

Technical Specifications

• Filling range 1 cc to 250 cc (With change of pump inserts)
• Tube dia upto 50mm
• Tube length upto 200 mm

Power Consumption

• Max 4.25 kw
• Min 1.5 kw

Air Consumption

• Max 7 CFM @ 6 kg/cm²
• Min 6 CFM @ 6kg/cm²2

Chilled water consumption

• 4 LPM @ 8-10^oC in case of hot air sealing system.

Standard Features with machine

• Manual tube infeed.
• Automatic tube orientation (option).
• Tail-free filling system.
• Smooth operation by using ferguson drive.
• Automatic coading on the tubes.
• Machine cladded with SS 304.
• Inbuilt centralised lubrication (option).
• No tube, no fill device.

Tube Closing station

• Option 1 : Metal folding & crimping station.
• Option 2 : Lamisealer for laminated or plastic tubes.
• Option 3 : A combination sealer for both metal tube folding, laminated & plastic tube sealing.

Optional Feature with machine

• Automatic tube infeed cassette system.
• Automatic tube cleaning system.
• Both side batch coating system.
• Cap tightening system
• Tubular cover aluminium or SS 304 with Acrylic or polycarbonate housing.
• Jacketed hopper with product stirring device.
• Electronic product counter & time totaliser.
• Reverse / Saddle folding on Aluminium.
• Flame proofing.
• Multicolour filling system.
• Designer sealing patterns.
• GMP version.
• PLC based machine operations.
• Before and after filling nitrogen pursing.
• Mechanical tail-free attach filling device.

Machine Weight

• Rotomax A/L tubefiller 525 kgs
• Rotomax C Tubefiller 650 kgs
