Contact Supplier| Engine & Performance | |
| Type | SI, 4 stroke, Oil cooled, Fuel injected |
| Engine Capacity | 177.4 cm3 |
| Max. Engine output (kW @ rpm) | 12.35 kW @ 8500 rpm (16.79 PS @8500 rpm) |
| Max. Torque (Nm @ rpm) | 15.5 Nm @ 7000 rpm |
| Valve per cylinder | 2 Valves |
| Starting | Electric Start |
| Power to Weight Ratio | 0.0876 kW/kg |
| Cooling System | Oil cooled |
| Gear box | 5 speed gear box |
| Chassis, Suspension & Electrical | |
| Type | Double Cradle Synchro STIFF |
| Front Suspension | Telescopic Forks |
| Rear Suspension | Monotube Inverted Gas-filled shox (MIG) with spring aid |
| Battery rating (Ah) | 12V, 8Ah MF |
| Headlamp* | Halogen HS1 12V 35/35W with AHO, Clear lens with MFR with LED position lamp |
| Tail Lamp | LED |
| Wheel, Tyre & Brake | |
| Tyre (front) | 90/90-17 49P Tubeless |
| Tyre (rear) | 110/80-17 57P Tubeless |
| Front Brake (Disc) | 270mm dia Petal Disc |
| Rear Brake (Disc/Drum) | 200mm dia Petal Disc |
| Brake Fluid | DOT 3 / DOT 4 |
| ABS | Single Channel Super-Moto ABS |
| Dimensions, Weight & Fuel Tank Capacity | |
| Height | 1105 mm |
| Length | 2085 mm |
| Width | 730 mm |
| Wheelbase | 1300 mm |
| Ground Clearance | 170 mm |
| Saddle Height | 790 mm |
| Kerb weight (with 90% fuel and tool kit) | 141 kg |
| Capacity (l) | 12 |
