Turning Type Alloy-wire Drawing Machine

We offer turning type alloy-wire drawing machine.
Usage:This type is used for drawing Nickel Alloy wire or Copper Alloy wire from 1.5mm to 0.4mm-0.8mm
Main Spec:
Machine type
JCJX-FZ17A
Control system
Dual inverter+PLC+HMI
Drawing dies No.Max.
17
Max. Inlet diameter
Ø 1.50mm
Outlet diameter
Ø 0.40--0.80mm
Max. Drawing line speed
240mmin
Capstan
Tool steel
Main motor
5.5KW
Spooler motor
1.1KW
Spool bobbin size
DIN160200250
or according to customers requirements
Traversing unit
Stepping motor
Transmission type
Teeth belt + Flat belt
Max .loading capacity
50KG
Lubrication type
Full immersed
Power source
380V 5060HZ or others
Machine dimension (mm)
2000×1600×1900
Machine weight
2500KG
