Twin Laser Beam Scanning & Electrophotographic Printing

Configuration Desktop
 Scanning Element One Dimension solid scanning through
 CCD
 Printing Process Twin Laser Beam Scanning &
 Electrophotographic Printing
 Toner Dry, Dual Component
 System Memory (RAM) Print/Scan: 1 GB RAM
  (Min./Max.)
 Hard Disk Drive Print/Scan: 128 GB Standard
 Document Feeder 100-Sheet ARDF (Standard)
 Copy Resolution 600 x 600 dpi
 Grayscale 256 levels
 Exposure Adjustment Manual & Automatic (Standard)
 Quantity Indicator Up to 999
 Original Type Book/Sheet
 Maximum Original Size Up to 11" x 17"
 Copy Size 5.5" x 8.5" to 11" x 17"
 Copy Type Plain Paper, Transparencies, Recycled
 Paper, Cardstock, Letterhead, Envelope
 First Copy Speed MP 4002: 4.1 seconds
 MP 5002: 3.5 seconds
 Continuous Copying MP 4002: 40 copies/minute (LTR)
  Speed MP 5002: 50 copies/minute (LTR)
 Warm-Up Time Print/Scan: Less than 19 seconds
  (from main Switch On)
 Recovery Time from Print/Scan: Less than 11/15 seconds
  Sleep Mode (MP 4002/MP 5002)
 Typical Electricity MP 4002: 2.87kWh (Print/Scan)
  Consumption (TEC) MP 5002: 3.49kWh (Print/Scan)
 Power Source 120V/60Hz, 12A
 Sleep Mode Print/Scan: 2.7W (MP 4002/MP 5002)
  Power Consumption
 Dimensions 26.38" (W) x 26.85" (D) x 35.24" (H)
 (670 x 682 x 895 mm)
 Weight Less than 213.8 lbs. (97 kg)
 Standard Paper 550 sheets x 2 trays
  Capacity 100-Sheet Bypass Tray
 Optional Paper 550 sheets x 2 trays or
  Capacity 2,000 x 1; 1,200-Sheet Large Capacity
 Tray (LCT)
 Paper Size Tray 1 & 2: 7.25" x 10.5" to 11" x 17"
 (Executive   A3); Bypass: 5.5" x 8.5"
 (SEF) to 11" x 17" (A5   A3)
 Paper Weight Tray 1 & 2: 16   57 lb. Bond/60   216 g/m2
 Bypass: 14   58 lb. Bond/52   220 g/m2
 Duplex: 16   44 lb. Bond/60   169 g/m2
 Reduction Ratios 25%, 50%, 65%, 73%, 78%, 85%, 93%
 Enlargement Ratios 121%, 129%, 155%, 200%, 400%
 Zoom 25% to 400% in 1% increments
 Standard Features Auto Magnification, Auto Paper Select,
 Auto Tray Switch, Center/Border Erase,
 Chapters, Combine Mode, Cover
 Insertion, Date Stamp, Directional
 Magnification, Double Copy, Electronic/
 Rotate Sorting, Preset Stamps, Bates
 Stamp (numbering), Full-Color WVGA
 Touch Screen, 25 Job Programs,
 Negative/Positive, OHP Slip Sheet,
 Page Number Stamp, Paper Designate,
 Sample Copy, Simple Screen, 1,000
 User Codes, Document Server,
 Stamping on Copies
