UL 1015 PVC Insulated Electric Wire

AWM 1015 electrical lead wire is the PVC insulated 105 C degree temperature resistant wire with stranded tinned copper conductor. Package could be coils, spools, cartons. pallets as per you needs. Detailed Examination as below:Physical Properties, Aging test, Flame test, Spark test. The PVC insulation material we used with excellent heat resistance and mechanical property. We offer other properties opinions for you to choose such as: - Oil resistance - Cold resistance  - Rat and insects resistance. This wire mostly used for internal wiring of electronic and electrical equipment.  Application examples as household appliance wiring assembly, motors, electric tools and lighting etc.  Technical Date: - Rated temperature: 105℃ - Rated voltage: 600V - Reference standard: UL subject 758, UL1581 - Conductor: 30-10AWG tinned or bare, stranded or solid copper - Insulation: Color-coded PVC - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test Conductor Insulation AWG NO.mm Diametermm Thicknessmm OverallDiametermm MaximumResistance at 20℃Ω/km 30 7/0.102 0.30 0.80 1.90 354.33 28 7/0.127 0.38 0.81 2.00 223.75 26 7/0.160 0.48 0.81 2.05 139.76 24 11/0.160 0.61 0.80 2.20 88.36 22 17/0.160 0.76 0.82 2.40 60.16 20 21/0.178 0.94 0.81 2.55 38.58 18 34/0.178 1.20 0.80 2.80 22.98 16 26/0.254 1.50 0.80 3.10 15.06 14 41/0.254 1.88 0.79 3.45 9.59 12 65/0.254 2.36
