UL 1332 FEP High Temperature Resistance Wire

AWM style 1332 high temperature resistant teflon wire is the FEP used for many applications during our daily life such as lighting lamps, home appliances, temperature sensors, mini motors, electromagnetic coils, automotive connection cables, industrial machines and various thermal places. Properties of FEP insulation material: - Excellent heat resistance up to 200℃. - Excellent chemical gas and oil resistant - Hot soldering iron resistant - Flame retardant & self extinguishing Technical Date: - Rated temperature: 200℃ - Rated voltage: 300V - Reference standard: UL subject 758, UL1581 - Conductor: 30-16AWG tinned or bare, stranded or solid copper - Maintains small dielectric constant and loss at high temperature and high frequency - Insulation: Color-coded FEP insulation with no mark - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1 flame test - Excellent electrical insulation properties, excellent resistance to oils, chemicals, solvents  and  oxidation Conductor Insulation AWG NO.mm Diametermm Thicknessmm Diametermm Approx.Weightkg/km MaximumResistance at 20℃Ω/km DielectricStrengthV(AC)/min 30 7/0.102 0.30 0.55 1.40 3.88 354 2000 28 7/0.127 0.38 0.55 1.48 4.50 223 26 7/0.160 0.48 0.55 1.58 5.38 139 24 7/0.203 0.60 0.55 1.70 6.64 86 22 7/0.254 0.78 0.55 1.88 8.67 55 20 7/0.320 0.96 0.55 2.06 11.13 35 Package options:
