UL1015 PVC Insulated Stranded Copper Wire

UL1015 lead wire is the PVC insulated electrical wire with stranded tinned annealed copper wire used for internal wiring of electronic and electrical equipment. Applications such as household appliance wiring assembly, motors, electric tools and lighting etc.  PVC insulation material is the material with excellent heat resistance and mechanical property has multiple opinions for you to choose such as oil resistance, cold resistance even rat and insects resistance. Technical Date: - Rated temperature: 105℃ - Rated voltage: 600V - Reference standard: UL subject 758, UL1581 - Conductor: 30-10AWG tinned or bare, stranded or solid copper - Insulation: Color-coded PVC - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test Conductor Insulation AWG NO.mm Diametermm Thicknessmm OverallDiametermm MaximumResistance at 20℃Ω/km 30 7/0.102 0.30 0.80 1.90 354.33 28 7/0.127 0.38 0.81 2.00 223.75 26 7/0.160 0.48 0.81 2.05 139.76 24 11/0.160 0.61 0.80 2.20 88.36 22 17/0.160 0.76 0.82 2.40 60.16 20 21/0.178 0.94 0.81 2.55 38.58 18 34/0.178 1.20 0.80 2.80 22.98 16 26/0.254 1.50 0.80 3.10 15.06 14 41/0.254 1.88 0.79 3.45 9.59 12 65/0.254 2.36 0.80 3.
