UL1330 FEP Insulated High Temperature Lead Wire

AWM 1330 wire is the FEP insulated tinned copper high temperature wire used for internal wiring of electronic and small electrical equipmentsuch as household appliances, lighting devices, small motors, temperature sensors, electromagnetic coils, automotive interior cables,industrial machines and various thermal places.   FEP insulation material with excellent heat resistance up to 200℃. Technical Date: - Rated temperature: 200℃ - Rated voltage: 600V - Reference standard: UL subject 758, UL1581 - Conductor: 32-16AWG tinned or bare, stranded or solid copper - Maintains small dielectric constant and loss at high temperature and high frequency - Insulation: Color-coded FEP insulation with no mark - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1 flame test - Excellent electrical insulation properties, excellent resistance to oils, chemicals, solvents and oxidation. Conductor Insulation AWG NO.mm Diametermm Thicknessmm Diametermm Approx.Weightkg/km MaximumResistance at 20℃Ω/km DielectricStrengthV(AC)/min 30 7/0.102 0.30 0.55 1.40 3.88 354 2000 28 7/0.127 0.38 0.55 1.48 4.50 223 26 7/0.160 0.48 0.55 1.58 5.38 139 24 7/0.203 0.60 0.55 1.70 6.64 86 22 7/0.254 0.78 0.55 1.88 8.67 55 20 7/0.320 0.96 0.55 2.06 11.13 35 Package options:
