UL1332 FEP Insulated High Temperature Wire

UL1332 teflon wire is the FEP insulated 200C degree high temperature wire which generally used for small electrical equipment and internal wiring of electronic. With the properties of excellent chemical gas and oil resistance, hot soldering iron resistance and self extinguishing. We can produce this wire in long and continuous lengths. Applications examples: - Household appliances - Lighting devices - Industrial machines  - Small motors  - Temperature sensors - Electromagnetic coils - Automotive interior cables - Various thermal places Technical Date: - Rated temperature: 200℃ - Rated voltage: 300V - Reference standard: UL subject 758, UL1581 - Conductor: 30-16AWG tinned or bare, stranded or solid copper - Maintains small dielectric constant and loss at high temperature and high frequency - Insulation: Color-coded FEP insulation with no mark - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1 flame test - Excellent electrical insulation properties, excellent resistance to oils, chemicals, solvents  and  oxidation Conductor Insulation AWG NO.mm Diametermm Thicknessmm Diametermm Approx.Weightkg/km MaximumResistance at 20℃Ω/km DielectricStrengthV(AC)/min 30 7/0.102 0.30 0.55 1.40 3.88 354 2000 28 7/0.127 0.38 0.55 1.48 4.50 223 26 7/0.160 0.48 0.55 1.58 5.38 139 24 7/0.203 0.60 0.55 1.70 6.64 86 22 7/0.254 0.78 0.55 1.88 8.67 55 20 7/0.320 0.96 0.55 2.06 11.13 35 Package options:
