UL1430 XLPVC Extruded Tinned Copper Wire

AWM style 1430 zero halogen wire is the insulated tinned copper wire used for motor, household appliance, illumination & lighting, electric machine and electrical installation etc. internal wiring of electronic and electrical equipment. Our hook-up wire is available in a variety of insulations to meet your needs for temperature, ability to withstand wear and abrasion, electrical performance, or resistance to oil, solvents, and chemicals.                                                                                                                           Properties of XLPVC insulation material compared with PVC insulation material - more steady - more abrasion resistant - more environmentally friendly Technical Date: - Rated temperature: 105℃ - Rated voltage: 300V - Reference standard: UL subject 758, UL1581 - Conductor: 32-16AWG tinned or bare, stranded or solid copper - Insulation: Color-coded XLPVC - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test Conductor Insulation MaximumResistance at 20℃Ω/km AWG NO.mm Diametermm Thicknessmm OverallDiamete
