UL2651 PVC Insulated Lat Ribbon Wire

UL2651 flexible 105 C degree flat ribbon cable is the PVC or SR-PVC insulated tinned annealed copper wire used for sensors and internal wiring of electronic equipments etc. The Flat ribbon cable with excellent mechanical property is extra flexible and easy to cut and process. Extruded materials with PVC or SR-PVC are RoHS complaint. Conductor 1 marked with red or blue polarity strip Technical Date: - Rated temperature: 105℃ - Rated voltage: 300V - Reference standard: UL subject 758, UL1581 - Conductor: AWG26, AWG24, AWG22 tinned or bare, stranded or solid copper (2cores to 18cores) - Insulation: PVC or Semi-Rigid PVC with grey color - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test Conductor AWG Construction Pitchmm Corse InsulationThicknessmm Diameter mm MaximumResistance at 20℃Ω/km 26 7/0.16 1.5 2 0.45 1.4*2.9 139.76 3 1.4*4.4 4 1.4*5.9 5 1.4*7.4 6 1.4*8.9 7 1.4*10.4 8 1.4*11.9 9 1.4*13.4 10 1.4*14.9 11 1.4*16.4 12 1.4*17.9 13 1.4*19.4 14 1.4*20.9 15 1.4*22.4 16 1.4*23.9 17 1.4*25.4 18 1.4*26.9 24 1/0.2011/0.16 1.6 2 0.45 1.5*3.1 88.36 3 1.5*4.7 4 1.5*6.3 5 1.5*7.9 6 1.5*9.5 7 1.5*11.1 8 1.5*12.7 9 1.5*14.3 10 1.5*15.9 11 1.5*17.5 12 1.5*19.1 13 1.5*20.7 14 1.5*22.3 15 1.5*23.9 16 1.5*25.5 17 1.5*27.1 18 1.5*28.7 22 7/0.25417/0.16 1.8 2 0.45 1.7*3.5 60.16 3 1.7*5.3 4 1.7*7.1 5 1.7*8.9 6 1.7*10.7 7 1.7*12.5 8 1.7*14.3 9 1.7*16.1 10 1.7*17.9 11 1.7*19.7 12 1.7*21.5 `3 1.7*23.3
