UL3122 Silicone Rubber Wire With Braided Fiberglass Sleeve

UL3122 fiberglass braided silicone rubber insulation wire is the flame retardant wire with RoHS and REACH appliance. Conductor can be from 26AWG to 10AWG tinned or bare, stranded or solid annealed copper.  Silicone rubber insulation material makes this kind of wire keeps flexible even at -60℃ low temperature.  With excellent electrical insulation performance, stable chemistry performance, it has the properties of anti-aging, anti-acid, anti-oil, anti-alkali, anti-moisture, anti-fungus as well, this wire can be used for internal wiring of appliance where totally enclosed such as household appliance, lighting device, industrial machine, even high temperature furnace where rated temperature not exceeding 200℃. Technical Date: - Rated temperature: 200℃ - Rated voltage: 300V - Reference standard: UL subject 758, UL1581, UL62 - Conductor: 26-16AWG tinned or bare, stranded or solid copper - Insulation: Silicone rubber insulated, fiberglass braided with multiple colors to choose - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT2 flame test AWG Conductor Nom. Insulation Thickness mm Braid Thickness mm Finished Wire Diameter mm Max. Resistance At 20℃ Ω/km      No./mm  Cross Section      mm2 26 7/0.16 0.48 0.55 0.15 1.58 139.76 24 11/0.16 0.61 0.55 0.15
