UL3135 Silicone Rubber Insulated Wire

UL 3132 silicone rubber 600V electrical wire stranded with tinned annealed copper could bear high temperature not exceeding 200℃ and keep flexible at very low temperature. The wire can be used to household appliance, lighting device, industrial machine, even high temperature furnace etc. Properties of silicone rubber insulation: - High temperature resistant and flame retardant - Keeping flexible even at -60℃ low temperature - Aging resistant & Fungus resistant - Acid & alkali resistant - Oil & moisture resistant - Excellent electrical insulation performance & Stable chemistry performance.  Technical Date: - Rated temperature: 200℃ - Rated voltage: 600V - Reference standard: UL subject 758, UL1581, UL62 - Conductor: 26-16AWG tinned or bare, stranded or solid copper - Insulation: Silicone rubber insulated, fiberglass braided with multiple colors to choose - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT2 flame test AWG NO.mm Diametermm Thicknessmm OverallDiametermm MaximumResistanceat20°CΩ/km 26 7/0.160 0.48 0.76 2.04 139.76 24 11/0.160 0.61 0.76 2.17 88.36 22 17/0.160 0.76 0.76 2.32 60.16 20 21/0.178 0.94 0.76 2.50 38.58 18 34/0.178 1.20 0.76 2.76 22.98 16 26/0.254 1.50 0.76 3.06 15.06 Package options:
