UL3173 XLPE Insulated Colored Electronic Wire

AWM 3173 cross-linked polyethylene insulated electronic wire is LSOH wire with excellent heat resistance up to 125℃.  XLPE material compound is more steady, low dielectric loss than PVC insulation material.  With the properties of excellent electrical performance, aging resistance, chemical corrosion and strong load capacity as well, this wire  is used for general internal wiring of electronic appliance and electrical equipment lead wire of motor, lamp, high-performance appliance and equipment etc. Technical Date: - Rated temperature: 125℃ - Rated voltage: 600V - Reference standard: UL subject 758, UL1581 - Conductor: 22-10AWG tinned or bare, stranded or solid copper - Insulation: XLPE with multiple colors to choose - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test Conductor Insulation AWG NO.mm Diametermm Thicknessmm OverallDiametermm MaximumResistance at 20℃Ω/km 22 17/0.160 0.76 0.79 2.40 60.16 20 21/0.178 0.94 0.79 2.55 38.58 18 34/0.178 1.20 0.79 2.80 22.98 16 26/0.254 1.50 0.79 3.10 15.06 14 41/0.254 1.88 0.79 3.50 9.59 12 65/0.254 2.36 0.79 4.00 6.07 10 66/0.320 3.00 0.79 4.65 3.73 Package options:
