UL3239 Automotive Application XLPE Insulated Wire

UL3239 halogen free automotive wire is the XLPE insulated wire with stranded tinned copper conductor used for ignition system, ESP & ABS seat heating, LED instrument, and window control system of automotive wiring system. XLPE compound material insulation also with excellent heat resistance and mechanical strength is more steady, low dielectric loss than PVC material insulation. It has the properties of excellent electrical performance, aging resistance, chemical corrosion and strong load capacity as well. Technical Date: - Rated temperature: 105℃ - Rated voltage: 600V - Reference standard: UL subject 758, UL1581 - Conductor: 30-10AWG tinned or bare, stranded or solid copper - Insulation: XLPE with multiple colors to choose - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test Conductor Insulation AWG  NO./mm Diametermm Thicknessmm Diametermm MaximumResistance at 20℃ohm/km 24 19/0.127 0.64 0.55 1.74 94.2 24 19.0127 0.64 0.48 1.60 94.2 Package options
