UL3266 Cross Linked Polyethylene Electrical Wire

AWM UL 3266 electrical low voltage cable is the low smoke zero halogen (LSZH) cable used for general internal wiring of electronic appliance and electrical equipment lead wire. The higher thermal stability of XLPE cable means that this cable permits higher current carrying capacity during operation and under short circuit conditions. XLPE insulation material also with excellent heat resistance and mechanical strength is more steady, low dielectric loss than PVC insulation material. It has the properties of excellent electrical performance, aging resistance, chemical corrosion and strong load capacity as well. Applications: - Motor & Lamp  - High-performance appliance and equipment where rated temperature not exceeding 125℃. Technical Date: - Rated temperature: 125℃ - Rated voltage: 300V - Reference standard: UL subject 758, UL1581 - Conductor: 30-16AWG tinned or bare, stranded or solid copper - Insulation: XLPE with multiple colors to choose - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test AWG NO.mm Diametermm Thicknessmm OverallDiametermm MaximumResistance at 20℃Ω/km 30 7/0.100 0.30 0.38 1.00 381.00 28 7/0.127 0.38 0.38 1.20 239.00 26 7/0.160 0.48 0.38 1.30 150.00 24 11/0.160 0.61 0.38 1.40 94.20 22 17/0.160 0.76 0.38 1.60 59.40 20 21/0.178 0.94 0.38 1.80 36.70 18 16/0.254 1.17 0.38 2.10 23.20 18 34/0.178 1.20 0.38 2.10 23.20 16 26/0.
