UL3321 Automotive Application XLPE Insulated Wire

UL3321 XLPE Cable is insulated with the LSHF crosslinkable PE material.  Compared with PVC insulation material, XLPE material is much more steady and lower dielectric loss with excellent mechanical strength and heat resistance. It also has the properties of excellent electrical performance, aging resistance, chemical corrosion and strong load capacity as well.  Based on the properties above, such wire is especially suitable for internal wiring of automotive. Other applications e.g. general internal wiring of electronic appliance and electrical equipment lead wire of motor, lamp, high-performance appliance and equipment where rated temperature not exceeding 150℃.  Technical Date: - Rated temperature: 150℃ - Rated voltage: 600V - Reference standard: UL subject 758, UL1581 - Conductor: 30-10AWG tinned or bare, stranded or solid copper - Insulation: XLPE with multiple colors to choose - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test Conductor Insulation AWG NO.mm Diametermm Thicknessmm OverallDiametermm MaximumResistance at 20℃Ω/km 30 7/0.102 0.30 0.79 1.90 354.33 28 7/0.127 0.38 0.79 2.00 223.75 26 7/0.160 0.48 0.79 2.05 139.76 24 11/0.160 0.61 0.79 2.20 88.36 22 17/0.160 0.76 0.79 2.40 60.16 20 21/0.178 0.94 0.79 2.55 38.58 18 34/0.178 1.20 0.79 2.80 22.98 16 26/0.254 1.50 0.79 3.10 15.06 14 41/0.254 1.88 0.79 3.50
