UL3321 XLPE Insulation Low Smoke Zero Halogen Cable

AWM 3321 XLPE sheath UL style 600V hook up wire is the 0HLS (zero halogen low smoke) electrical wire confirmed to RoHS. General applications of this lead wire is used for internal wiring of electronic appliance and electrical equipment. Detailed applications: motor, lamp & lighting, water heaters, transformers, clothes dryers, cookers, toasters, gas heating, electric heating and other high-performance appliance and equipment where rated temperature not exceeding 150℃. XLPE insulation material also with excellent heat resistance and mechanical strength is more steady, low dielectric loss than PVC insulation material. It has the properties of excellent electrical performance, aging resistance, chemical corrosion and strong load capacity as well. Technical Date: - Rated temperature: 150℃ - Rated voltage: 600V - Reference standard: UL subject 758, UL1581 - Conductor: 30-10AWG tinned or bare, stranded or solid copper - Insulation: XLPE with multiple colors to choose - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test Conductor Insulation AWG NO.mm Diametermm Thicknessmm OverallDiametermm MaximumResistance at 20℃Ω/km 30 7/0.102 0.30 0.79 1.90 354.33 28 7/0.127 0.38 0.79 2.00 223.75 26 7/0.160 0.48 0.79 2.05 139.76 24 11/0.160 0.61 0.79 2.20 88.36 22 17/0.160 0.76 0.79 2.40 60.16 20 21/0.178 0.94 0.79 2.55 38.58 18 34/0.178 1
