UL3398 Low Smoke Zero Halogen XLPE Wire

UL3398 - General internal wiring of electronic appliance and electrical equipment UL style AWM 3398 low smoke halogen free electrical wire is the cross-linked polyethylene (XLPE) insulated wire used for many daily life applications such as motor, lamp & lighting, water heaters, transformers, clothes dryers, cookers, toasters, gas heating, electric heating and other high-performance appliance and equipment where rated temperature not exceeding 150℃. XLPE insulation material compared with PVC insulation material:  - More steady   - lower dielectric loss - Excellent heat resistance and mechanical strength  - Excellent electrical performance, aging resistance, chemical corrosion and strong load capacity Technical Date: - Rated temperature: 150℃ - Rated voltage: 300V - Reference standard: UL subject 758, UL1581 - Conductor: 32-16AWG tinned or bare, stranded or solid copper - Insulation: XLPE with multiple colors to choose - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test Conductor Insulation AWG NO.mm Diametermm Thicknessmm OverallDiametermm MaximumResistance at 20℃Ω/km 32 7/0.080 0.24 0.26 0.76 563.00 30 7/0.102 0.30 0.26 0.82 381.00 28 7/0.127 0.38 0.26 0.90 239.00 26 7/0.160 0.48 0.26 1.00 150.00 24 11/0.160 0.61 0.26 1.13 94.20 22 17/
