UL4411 XLPE Insulated Flat Ribbon Wire

UL4411 flexible flat ribbon sensor wire is the irradiated polyethylene insulated tinned copper wire with RoHS complaint. The form of flat ribbon cable with a web between conductors, may be used same or mixed AWG sizes. The flat ribbon wire assemble with 2-6 conductors has the features of small bending radius, high flexibility which can help you minimize waste of space. used for internal wiring of electronic equipments especially variety of sensors. Technical Date: - Rated temperature: 125℃ - Rated voltage: 300V - Reference standard: UL subject 758, UL1581 - Conductor: 32AWG-10AWG, tinned or bare, stranded or solid copper (2 cores to 6 cores) - Pitch: 1.20mm, 1.27mm, 1.50mm, 2.00mm, 2.50mm - Insulation: XLPE with multiple color option - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test Conductor Insulation Cores AWG NO/mm Diametermm mm mm MaximumResistance at 20℃Ω/km 2 32 7/0.080 0.24 0.38 1.00*2.10 542 2 30 7/0.100 0.30 0.38 1.10*2.30 381 2 28 7/0.127 0.38 0.38 1.20*2.50 239 2 26 7/0.160 0.48 0.38 1.30*4.30 150 2 24 11/0.160 0.61 0.38 1.40*2.90 94.2 2 22 17/0.160 0.76 0.38 1.60*3.30 59.4 2 20 21/0.178 0.94 0.38 1.80*3.70 36.7 Package
