Contact SupplierThe UL style 4413 halogen free flex flat ribbon sensor cable used for internal wiring of electronic equipments especially variety of sensors. It is the XLPE insulated with stranded tinned copper wire in compliance with RoHS standard.  This flat ribbon wire assemble with 2-6 conductors has the features of small bending radius, high flexibility which can help you minimize waste of space. The form of flat ribbon cable with a web between conductors, may be used same or mixed AWG sizes. Technical Date: - Rated temperature: 150℃ - Rated voltage: 300V - Reference standard: UL subject 758, UL1581 - Conductor: 32AWG-16AWG, tinned or bare, stranded or solid copper (2cores to 6cores) - Insulation: XLPE with multiple color option - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test Conductor Insulation Cores AWG NO/mm Diametermm mm mm MaximumResistance at 20℃Ω/km 2 32 7/0.080 0.24 0.38 1.00*2.10 542 2 30 7/0.100 0.30 0.38 1.10*2.30 381 2 28 7/0.127 0.38 0.38 1.20*2.50 239 2 26 7/0.160 0.48 0.38 1.30*4.30 150 2 24 11/0.160 0.61 0.38 1.40*2.90 94.2 2 22 17/0.160 0.76 0.38 1.60*3.
