UL4484 XLPE Insulated Halogen Free Flat Ribbon Wire

UL4484 flex flat ribbon sensor cable is the XLPE insulated tinned copper wire with RoHS complaint used for internal wiring of electronic equipments especially variety of sensors detecting water temperature. The flat ribbon wire assemble with 2-6 conductors has the features of small bending radius, high flexibility which can help you minimize waste of space. The form of this kind of flat ribbon cable may be used same or mixed AWG sizes insulated conductors bonded together or co-extruded in such a fashion. Similar cables may be formed from twisted pairs bonded together in a 2-6 conductor assembly. Technical Date: - Rated temperature: 150℃ - Rated voltage: 300V - Reference standard: UL subject 758, UL1581 - Conductor: 32AWG-18AWG, tinned or bare, stranded or solid copper (2cores to 6cores) - Insulation: XLPE with multiple color option - Uniform insulation thickness to ensure easy stripping and cutting - Passed UL VW-1, cUL FT1 and JQA F-mark flame test Conductor Insulation Cores AWG NO/mm Diametermm Thickness mm Dia. mm MaximumResistance at 20℃Ω/km 2 30 7/0.100 0.30 0.20 0.80*1.70 381 2 28 7/0.127 0.38 0.20 0.90*1.90 239 2 26 7/0.160 0.48 0.25 1.00*2.10 150 2 24 11/0.160 0.61 0.25 1.30*2.70 94.2 2 22 17/0.160 0.76 0.25 1.40*2.90 59.4 2 20 21/0.178 0.94 0.25 1.60*3.30 36.7 2 18 34/0.178 1.20 0.38 1.80*3.70 23.2 Package options:
