Ultrasonic hardness tester

Supply TypeManufacturer, Exporter, Supplier, Distributor
Preferred Buyer Location All over the world

The Ultrasonic Contact Impedance (UCI) probe is used for measuring the hardness value of small items, objects with a thin wall, complex form, and to measure the hardness of surface hardened....

View More Details

Send Enquiry

Company Information

Heat Treatment Sales & Services

Odhav, Ahmedabad, Gujarat

4.5/5

(2)

View Number

Member Since 15 Years
Nature of Business Manufacturer
GST No. 24ANYPS0431L1ZI

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

The Ultrasonic Contact Impedance (UCI) probe is used for measuring the hardness value of small items, objects with a thin wall, complex form, and to measure the hardness of surface hardened layers.

Built-in camera allows user to take a picture of testing object and mark tested area with corresponding hardness value.

UCI Hardness Tester NOVOTEST T-U3 has the sealed housing with rubber protective strips, it is ideal for use in workshop and field conditions with high humidity, dust, etc. Hardness tester has frost-resistant display, which allows user to use the device at any season and in any climatic zone of the Earth.

The device has PC software with a comfortable and intuitive interface.

Advantage:

Hardness measurement of any mass products with a thickness more than 1 mm
Measuring the hardness of the surface hardened layer
Small imprint after measuring (mirror surfaces of shafts necks, blades, gear teeth, etc.)
Wide range of hardness testing
Various measurement modes
Calibration of any scale in any range
Convenience and ease for measurement
Optimized number of buttons
Large full color graphic display with bright back-lighting
Calibrations stored in memory of probe
Extended temperature range (frost, down to – 40°C)
Internal memory and communication with PC
New, intuitive menu with tips on the buttons
Optional wireless mini printer
Water resistant case
Has different operating modes:
Graph – the mode of building of graph
Histogram – the mode of building of histogram
Statistics – the mode of statistic
Smart – the mode of filtering of incorrect measurement

Additional Information:

Item Code - T-U3
Approx. Rs 1.30 Lakh / Piece(s)
UCI Hardness Tester NOVOTEST T-U3

Technical Specifications

UCI probe types	1kgf (10N) 2.2 lbf, 5kgf (50N) 11lbf, 10kgf (98N) 22lbf
Measuring range (with standard calibration)	HV:230~940; HRC:20~70; HB:90~650. Tensile strength, MPa 370~1740
Measuring accuracy	HV:±3%HV; HRC:±1.5%HRC; HB:±3%HB
Indenter	Diamond indenter (UCI)
Measuring direction	Any direction 360°
Data storage	Limited only by the memory card
Communication	Upload data to PC and export as a spreadsheet (USB cable and software included )
Hardness scale	HRC, HB, HV, HRB, HS, HL, MPa
Materials	Pre-calibrated for steel, has calibration scales for additional custom materials
Data display	Load applied/contact (UCI), Single test result, Max, Min, Average of tests, Number of tests, Deviation, Var. coeff, Histogram, Signal and Smart Mode (Filter of incorrect measurements)
Indication	Color LCD display (320×240)
Operating environment	Temperature:-20°C~40°C; Humidity: 30%~80%R.H.
Power supply	DC 4,5V (3 pcs batteries AA)
Instrument dimensions	160x75x30mm
Net weight	Approx. 0.3kg (without probe)
Batteries life	Approx. 10 hours
