Ultrasonic Open Channel Flowmeter

We are offering ultrasonic open channel flowmeter.
Auf790 series is a fixed mounted, open channel ultrasonic flowmeter, with clamp-on transducer used for non-invasive
measurement. Our microprocessor based, user friendly, field programmable flow measurement technique allows no interruption of the process flow
and has low installation costs.
Features
4 line lcd display with flowrate, totalizer & level condition
v-notch, rectangular with and without end contractions, cipolletti.
Parshall, palmer-bowlus, leopold-lagco, trapezoidal, h.
A sampler relay will signal your sampler to collect flow proportion
high accuracy of +-0.8% of reading
non-contact flow measurement
exclusive sensor for open channel flow
response time less than 1 second
specification
measuring principle:ultrasonic sound
measuring range:level 0-3 meter
flow rate:0-10,000 m3min
material:ultrasonic tube abs
display: line lcd with illumination (separate version) 2 line lcd with illumination (compact version)
ambient temperature:-20 ~ +60 deg.c
max. Cable length: 50m
power consumption:less than 3w
power supply:90 ~ 260vac, 5060 hz or 15-36vdc
data storage:
operation parameters and totalization date are stored by eeprom for more than 10 years
alarm:highlow
communication:rs-485 (modbus)
dimensions: compact 125mm(w)*230mm(h)*170mm(d) separate 240mm(w)*210mm(h)*120mm(d)
weight:3.5 kg(compact), 2.2 kg(separate)
enclosure:ip65 explosion proof, ex d (ia) ii b t4
