UNI-Tube Armoured Fiber Optic Cable

Company Information

Ask for more detail from the seller

Report incorrect details

Cable TypeUni-tube Armoured Cable
Brand NameLumiflex
Lengths(tolerance ±5%)500meter,1km
Sheath Printing DetailsLumiflex Fiber Type, Fiber Count, Product Type, Month and Year of Production, Special Id, Meter Mark
FiberUp to 24,Gel -filled
Note:Customised Drum Lengths Available On Request.
Fiber TypeSingle-mode or Multimode
Sheath optionSingle PE Sheath
Operating Temperature-40℃ +70℃
CompliancesIn Accordance with IEC,ITU and EIA standards
Strength MemberParellel Steel Wire
PackingWooden drums /Plastic Drum

It is a long established fact that a reader will be distracted by the readable content of a page when looking at its layout.

Colors

Fiber Standard Colour Code

It is a long established fact that a reader will be distracted by the readable content of a page when looking at its layout.

Feature

Application

Fiber transmission performance

It is a long established fact that a reader will be distracted by the readable content of a page when looking at its layout.

Optical Fiber (dB/km)	G652D (1310nm/1550nm/1625nm)	G657A1 (1310nm/1550nm/1625nm)	G657A2 (1310nm/1550nm/1625nm)
Max attenuation	0.4/0.3/0.3	0.4/0.3/0.3	0.4/0.3/0.3
Typical value	≤0.35/0.23/ 0.26	≤0.35/0.23/ 0.26	≤0.35/0.23/ 0.26

Technical Specification

It is a long established fact that a reader will be distracted by the readable content of a page when looking at its layout.

Cable type	Maximum cores	Cable diameter(mm)	Tensile Strength		Crush Resistance		Mimimum bend radius

			Short term	Long term	Short term (N/100mm)	Long term (N/100mm)	Dynamic	static
UNI-TUBE ARMORED	2	5	3000	1000	1000	300	20D	10D
UNI-TUBE ARMORED	4	7.2	3000	1000	1000	300	20D	10D
UNI-TUBE ARMORED	6	7.2	3000	1000	1000	300	20D	10D
UNI-TUBE ARMORED	12	7.2	3000	1000	1000	300	20D	10D
UNI-TUBE ARMORED	24	7.2	3000	1000	1000	300	20D	10D
