3 PHASE TRANSFORMER LAB TRAINER

We are offering 3 phase transformer lab trainer
1. load test on three phase transformer
2. study of transformer connections in various configurations
3. star-delta, delta-star, star-star, delta-delta
4. ratio and efficiency test.
5. polarity test
6. open and short circuit test
features:
electrical control panel with 3 phase 3kva transformer. (3kva)
• control panel will size 42”x24”
• transformer provided will be high quality copper wound
• primary will be 440v and secondary of the transformer will be 220v.
• panel consist of ms powder coated housing with back side removable.
• transformer will be differently housed in a ms powder cabinet for easy carrying and other general use.
• electrical panel fitted with front panel of high class insulated bakelite sheet 6mm thick.
• it is fitted with appropriate analog or digital voltmeter, ammeter to record the readings.
• short circuit protection with the help of mcb.
• 1 nos. 8a variable ac supply is provided separately through variac for short circuit test.
• load bank is provided separately with mobility and for it can be used for other general use.
• connections through 4mm safety terminals
• supplied with instruction manual
