TECHNICAL DATA
| Parameters | Unit | Specification | |
|---|---|---|---|
| MILLING SPINDLE: | |||
| SPINDLE NOSE | ISO | ISO-40 | |
| NUMBER OF SPEEDS | NUMERIC | 18 NOS | |
| SPEED RANGE (MIN. / MAX.) | RPM | 35 ~ 1750 | |
| DISTANCE BETWEEN SPINDLE AXIS TO TABLE SURFACE | MM | 70-465 (Min/Max.) | |
| DISTANCE OF SPINDLE AXIS TO BOTTOM SURFACE OF OVER ARM | MM | 155 | |
| TABLE: | |||
| GENERAL DIMENSION (LENGTH X WIDTH) | MM | 1525 X 300 | |
| NUMBER OF T-SLOTS | NUMERIC | 3 | |
| WIDTH OF T-SLOTS | MM | 16 | |
| CENTER DISTANCE OF T-SLOTS | MM | 65 | |
| MINIMUM DISTANCE LEFT HAND TABLE END TO SPINDLE CENTER | CENTER MM | CENTER MM 250 | |
| SWIVEL OF TABLE | DEGREE | 45° | |
